System requirements
Operating systems
Recommended
RHEL 7.4
Microsoft Windows Server 2012 R2 or Microsoft Windows 10 64 bit only
Supported
RHEL 7.3, 7.4, 7.5
Microsoft Windows Server 2016, 2012, 2012 R2, 2008 R2; Windows 7, 8, and 10 64 bit only
Hardware requirements
Recommended for Development environment (with AutoML cluster)
# |
OS | Description |
CPU |
RAM (GB) |
HDD |
1 |
Linux | APP (Application) |
8 |
32 |
250 GB |
| 2 | Linux | DB (Database) | 4 | 16 | 1 TB |
3 |
Linux | OCR * |
4 |
16 |
100 GB |
4 |
Linux | AutoML Master, NFS * |
8 |
32 |
250 GB |
| - | AutoML NFS share * | - | - | 2 TB | |
| 5 | Linux | AutoML Agent * | 8 | 32 | 250 GB |
| 6 | Linux | AutoML Agent * | 8 | 32 | 250 GB |
| 7 | Linux | AutoML Agent * | 8 | 32 | 250 GB |
| 8 | Linux | PM (Platform Monitor) * | 2 | 4 | 100 GB |
| 9 | Windows | RPA (5 nodes) * ** | 8 | 16 | 250 GB |
| 10 | Windows | BI (Analytics) * | 4 | 16 | 100 GB |
Recommended for Production environment
# |
OS | Description |
CPU |
RAM (GB) |
HDD |
1 |
Linux | APP (Application) |
8 |
32 |
250 GB |
2 |
Linux | DB (Database) |
8 |
32 |
1 TB |
3 |
Linux | OCR * |
8 |
32 |
250 GB |
4 |
Linux | AutoML Master *** |
8 |
32 |
250 GB |
| 5 | Linux | AutoML Agent * | 8 | 32 | 250 GB |
| 6 | Linux | PM (Platform Monitor) * | 2 | 4 | 100 GB |
| 7 | Windows | RPA (5 nodes) * ** | 8 | 16 | 250 GB |
| 8 | Windows | BI (Analytics) * | 8 | 32 | 250 GB |
* The server is required only if the functionality is used
** The RPA component is installed on the environment mimicking business operations environment with all the applications required to complete the task(s).
*** AutoML HPO training is performed on Development environment. For AutoML training to be possible on Production environment - full size cluster with NFS is required.
Unless stated otherwise, "Disk space" denotes the addressable space left on the single partition where you plan to install the software after the disk has been formatted with a filesystem.
For the installation it is advised to use HDD/SDD volumes mounted separately from the root volume of the operating system.
Recommended amount of AutoML Agents may vary, maximum amount up to 10
Once Environment with the required capacity is prepared, proceed to the Installation overview section.
Virtualized environments
In addition to working on physical servers, all of WorkFusion’s products operate in virtualized environments, provided they are configured with the proper underlying operating system and minimum resource requirements. Known compatible virtualized environments: Citrix environments, Microsoft Hyper-V, Parallels, VMware vMotion, VMware vSphere, Amazon Web Services, Google Cloud Platform and Microsoft Azure.
Capacity planning
The system requirements described are suitable for most of the typical automation projects and are recommended as a baseline for running Workfusion SPA in production. If you want to scale these recommendations, i.e. add more memory, or more CPU, you may have to tune other components in the SPA stack, like the JVM heap settings, or the MySQL max connections.
For these types of capacity changes and for detailed capacity and scaling planning, refer to Infrastructure capacity planning.
